Ampli 120W InterM PA-120A
Feature
● High Efficiency Class-D Amplifier
- High efficiency, low power consumption due to Class-D amplifier.
● Various Input Terminal
- 3 MIC Inputs, 2 Line Inputs, 1 Stereo Line Input, TEL IN and EXT IN input
● Input / Output Monitoring
- Built-in input signal display LED and output level display LED (7 Dots) per channel
● Tone Control
- Depending on the frequency used, there are treble and bass controllers to adjust the tone to suit your surroundings and purpose. (At 100Hz and 10kHz,each adjustable ± 10dB)
● Speaker Selection Switch
- Selective-zone / All-zone broadcast by 5 speaker selection switches and a switch for all.
● Priority Broadcast Function
- Priority broadcasting function is adopted which can control other input signals by input signal of TEL IN and INPUT 1. (TEL IN >> INPUT 1 >> INPUT 2~6)
● User Friendly Features
- Chime and Siren, EXT IN, MIX OUT
● Phantom Power Support
- PHANTOM POWER support for high intensity condenser microphone (INPUT 1~3)
| Model | PA-60A | PA-120A | PA-240A | |
| Output Power | 70V/100V | 60W | 120W | 240W |
| (1kHz, THD 1%) | 8Ω | 40W | 120W | 180W |
| 4Ω | 60W | 160W | 240W | |
| Frequency Response (1W, ±3dB) |
LINE | 80Hz~17kHz | ||
| MIC | 100Hz~15kHz | |||
| THD+N (Rated Power, 1kHz) | 1% max | |||
| S/N | LINE | More than 70dB | ||
| MIC | More than 50dB | |||
| Input Sensitivity / Impedance | ||||
| Input 1~5/input impedance | MIC | -70dBu / 2kΩ (Balanced) | ||
| LINE | -20dBu / 2kΩ (Balanced) | |||
| Input 6/input impedance | RCA | -20dBu / 2kΩ (UnBalanced) | ||
| -10dBu / 10kΩ (UnBalanced) | ||||
| TEL IN/input impedance | -20~0dBu / 10kΩ (Balanced) | |||
| EXT IN/input impedance | 0dBu / 20kΩ (Balanced) | |||
| MIX OUT/input impedance | 0dBu / 10kΩ (Balanced) | |||
| Speaker output level / output impedance | 100V / 167Ω | 100V / 84Ω | 100V / 42Ω | |
| 70V / 82Ω | 70V/ 41Ω | 70V / 21Ω | ||
| TONE CONTROL | 10dB | |||
| Operating Temperature | -10℃ ~ +40℃ | |||
| Operating Power | AC 220V, 230V, 240V, 50/60Hz | |||
| Power consumption (1/8W output) | 40W | 60W | 90W | |
| Weight (set) | 6.25kg/13.78lb | 7.32kg/16.14lb | 9.75kg/21.5lb | |
| Dimensions (set) | 420(W) x 88(H) x 318.7(D)mm | |||
