Mixer Behringer WING COMPACT
48-Channel, 28-Bus Full Stereo Digital Mixing Console, with 24-Midas PRO Preamps, 8 Midas PRO Outputs, 10.1" Touch Screen and 13-Fader Control Surface

  • 24 Midas PRO mic preamps and 8 outputs provide industry-reference sound quality
  • 13 motorized 100 mm faders with powerful master fader section - and 20 Custom buttons
  • 3 AES50 ports for a total of 144 input and output signals on SuperMac CAT5 connections with ultra-low jitter and 6-sample latency
  • 10.1 inch main display with multi-touch screen and adjustable swivel
  • Unique “Sends on Fader”-Workflow with dedicated color TFT-Display and dedicated hot-keys to 44 Masters - Buses, Mains, Matrices, DCA's
  • Integrated USB Audio/MIDI Interface for 48 audio channels in and out
  • Dual-SD card live recorder/player with up to 64 tracks and markers for identifying song positions
  • Internal AoIP-module can upgrade the Ethernet ports with optional 64 channel audio in and out to Audinate Dante and Waves SoundGrid networks
  • 16 True-stereo effects processing engines, with 80+ world-class algorithms
  • 3 plug-in slots for Gate, Dynamics and EQ included in every channel. All without reducing any additional effect processing headroom
  • 4 main, 8 matrix and 16 aux stereo buses, featuring dual inserts, 8-band parametric EQ's, stereo imager and full dynamics processing, all in a single effect chain
  • 40 Stereo Input Channels with 5 variable plug-in processing slots each
  • 8 Stereo Aux Input Channels with single FX insert slot, expander/limiter and 4-band parametric EQ
  • 8 Mute Groups and 8 DCA's for track grouping and consolidation
  • 2 Ethernet ports with integrated switch for networked remote control and optional AoIP through Waves SoundGrid and Dante®
  • Rear panel expansion slot can host optional 64-channel audio interface and networking expansion cards, e.g. Dante, WSG, MADI …
  • StageConnect Host interface for sharing of up to 32 channels in either direction via single XLR connection
  • 2 channel GPIO for controlling almost anything with WING
  • 5-Pin MIDI in and out for control and synchronization with external devices
  • DAW Remote Control compatible with Mackie Control Universal (MCU) and presets for Cubase, Ableton Live, Logic X, Nuendo, ProTools, Reaper, Studio One
  • Offline editing and remote control via WING-CoPilot, WING-Q and WING-Edit Softwares for Desktop and Mobile
  • 19" rack-mountable in 3 positions



Input/Output Characteristics
Frequency response @ 48 kHz sample rate, 0 to -1 dB (any gain setting)
10 Hz - 20 kHz
Dynamic range, analog in to analog out (typical), XLR / aux
111 dB / 108 dB
A/D dynamic range, preamplifier and converter (typical), XLR / aux
112 dB / 110 dB
D/A dynamic range, converter and output (typical), XLR / aux
118 dB / 112 dB
Crosstalk rejection @ 1 kHz, adjacent channels
100 dB
Output level, XLR connectors (nominal / maximum)
+4 dBu / +21 dBu
Output impedance, XLR connectors (unbalanced / balanced)
75 Ω / 75 Ω
Input impedance, TRS connectors (unbalanced / balanced)
20 kΩ / 40 kΩ
Non-clip maximum input level, TRS connectors
+16 dBu
Aux output level, TRS (nominal / maximum)
+4 dBu / +16 dBu
Aux output impedance, TRS (unbalanced / balanced)
150 Ω / 300 Ω
Phones output impedance / maximum output level
1W Max @ 30 Ohm
Residual noise level, XLR out 1-16 connectors, unity gain
-97 dBu
Residual noise level, aux and monitor TRS out connectors
-95 dBu
Displays
Main screen
10.1" TFT LCD, 1280 x 800 px, capacitive touch
Main screen swivel, continuous adjustment
15°- 60°
4-channel group LCD screen with RGB color strip per channel
320 x 48 monochrome
Controls
100 mm motor faders
12 + 1
Touch-sensitive rotary controls
3 + 7 + 11 + 4 + 4
Custom controls
8
Fully assignable rotary controls
4
Fully assignable backlit buttons
8 + 8
Variable rotary controls / buttons
04-Apr
Power
Switch-mode power supply
Auto-ranging 100-240 VAC (50/60 Hz)
Power consumption
130 W
Physical
Standard operating temperature range
5°C – 40°C (41°F – 104°F)
Dimensions (HxWxD)
57.43 x 45.337 x 22.5 cm
Weight
15.92 kg
