Loa âm trần JBL Control 426LP

Mã sp : Loa âm trần JBL-C426LP

Hotline: 0908677003

6.5" CRBI™-Equipped Two-Way Coaxial Ceiling Loudspeaker with Low-Profile Enclosure

The JBL Control 426LP is a two-way coaxial ceiling loudspeaker, featuring a 6.5” woofer and a low-profile enclosure that is ideal for applications where ceiling plenum space is restricted. Integrated CRBI™ technology provides 110° of consistent, full, rich sound character that closely matches that of the Control 426C/T. A full-face magnetic grille blends seamlessly with modern decors and optional black and square grilles are available. Mechanical improvements include redesigned terminal covers with top and side cable entry ports and an extremely reliable new dogear design that works with a wide range of ceiling thicknesses. Like all Control 400 Enhanced Coverage models, the Control 426LP includes a transformer to support both 70V/100V and low impedance applications.

Coaxially mounted 165 mm (6.5 in) woofer and 25 mm (1.0 in) soft-dome tweeter

Low-profile enclosure (<100mm deep) for installing where ceiling plenum space is restricted

CRBI™ technology for consistent sound coverage

Built-in 70V/100V multi-tap transformer, plus 12-ohm direct input

Full-face, easily-paintable magnetic grilles

Black and square magnetic accessory grilles available

Top and side exit cable entry options

Robust and adaptable dogears for wide range of ceiling thicknesses

IP33 rated

Frequency Range (-10 dB)	95 Hz – 19 kHz
Power Capacity	110 W (440 W Peak), Continuous Pink Noise (2 hrs) 75 W (300 W Peak) Continuous Pink Noise Power (100 hrs)
Sensitivity (1m/1W)	89dB
Coverage Angle	110° conical
Maximum SPL (1m)	109 dB continuous pink noise (115 dB peak)
Nominal Impedance	12Ω
Transformer Taps	70 V: 60 W, 30 W, 15 W & 7.5 W 100 V: 60 W, 30 W, 15 W
Drivers	LF: 165 mm (6.5 in) with treated paper cone and high-performance magnet HF: 25 mm (1.0 in) textile soft-dome with Neodymium magnet assembly
Ceiling Cutout Size	223 mm (8.8 in)
Dimensions	107 mm (4.2 in) H x 253 mm (9.9 in) dia. 98 mm (3.9 in) from bottom of ceiling tile to top of backcan
Safety Agency Rating	Suitable for use in air handling spaces per UL2043, NFPA 90A & NFPA 70, CSA C22.2 no. 205 and S7232/UL1480A Listed.
Environmental	IP33 rating per EN/IEC 60529. Operating temperature 0°C to 45°C
Optional Accessories	JBL-MTC-426BG black (RAL9004) round grille JBL-MTC-426SG white (RAL9003) square grille JBL-MTC-426NC new construction bracket JBL-MTC-426MR mud-ring construction bracket JBL-MTC-48TRX4 tile rail for 4' x 4' ceiling tiles
Color	Stock grille is White (RAL9003), paintable
Net Weight (ea)	3.9 kg (8.6 lbs)
Shipping Weight (pair)	12.58 kg (27.73 lbs)
SKU Numbers	JBL-C426LP
