Mixer thu âm Zoom LIVETRAK L-20

Sản phẩm

Mixer thu âm Zoom LIVETRAK L20

Mã sp : Mixer thu âm Zoom LIVETRAK L20

Số lượng :

Quý khách vui lòng click các nội dung dưới đây để tham khảo các chính sách bán hàng của chúng tôi:

Giá bán: 28.000.000 Đ (giá tham khảo)

(Giá chưa bao gồm thuế 10% VAT)

Đặt hàng

Hotline: 0908677003

Mô tả sản phẩm
Thông số kỹ thuật

Mixer thu âm Zoom LIVETRAK L-20
20 discrete channels (16 mono plus 2 stereo) with XLR or ¼-inch connectivity
22-track simultaneous recording, 20-track playback
22-in/4-out USB audio interface connectivity
Records up to 24bit/96kHz audio to SD card
48V phantom power
Hi-Z connectivity (channels 1-2)
26dB pad (channels 3-16)
Built-in compression control (Channels 1-16)
Solo buttons for individual channels
Variable frequency low-cut control
Main outputs plus 6 customizable monitor outputs
Dedicated headphone output for sound engineer
Scene saving function, up to 9 scenes saved at a time
20 built-in chorus, delay and reverb effects with adjustable parameters
Two effect busses
Built-in slate mic
Class-compliant mode (for iOS compatibility)
Compatible with Remote Mixer app for iPad
Automatic recording starting/stopping capability
Pre-record function
Import/export projects with USB 2.0 host port
Compatible functions for ZOOM FS01 footswitch
Automatic power-save function
WHAT'S IN THE BOX
INCLUDED WITH THE L-20
LiveTrak L-20
AD-19 AC Adapter
USB 2.0 Cable
Quick Guide
OPTIONAL ACCESSORIES
RKL-12 Rack Mount Adapter
BTA-1 Bluetooth Adapter
FS-01 Momentary Footswitch
CBL-20 Carrying Bag

INPUTS	Mono (MIC/LINE): 16 Stereo (LINE): 2
OUTPUT	MASTER OUT: 1 MONITOR OUT: 6 PHONES : 1
MASTER	1
MONITOR	6
SEND EFX	2
LOW CUT	40–600 Hz, 12dB/OCT
EQ	HIGH: 10 kHz, ± 15 dB, shelving \| MID: 100 Hz – 8 kHz, ± 15 dB, peaking \| LOW: 100 Hz, ± 15 dB, shelving
LEVEL SEGMENTS	12
EFFECTS \| 20 TYPES	EFX 1 Hall 1, Hall 2, Room 1, Plate, Church , DrumAmb , GateRev, Vocal 1 , Vocal 2 , Vocal 3
	EFX 2 Hall 3, Room 2, Spring Delay, Analog P-P Dly , Vocal 4, Chorus 1, Chorus 2
MAXIMUM SIMULTANEOUS RECORDING TRACKS	22 at 44.1/48/96 kHz
MAXIMUM SIMULTANEOUS PLAYBACK TRACKS	20
RECORDING FORMAT	WAV 44.1/48/96 kHz, 16/24-bit, mono/stereo
RECORDING MEDIA	4GB–32GB SDHC cards (Class 10 or higher) , 64GB–512GB SDXC cards (Class 10 or higher)
44.1/48 KHZ	Recording: 22 channels \| Playback: 4 channels
BIT DEPTH	24-bit
INTERFACE	USB 2.0
WINDOWS	OS： Windows® 8.1 ~ 11 (32bit/64bit) \| CPU: Intel® Core i3 or faster* \| USB: USB 3.0/USB 2.0** * Operation is not guaranteed with CPUs from Atom, Celeron or Pentium series or CPUs made by AMD. ** Only USB host controllers with Intel Chipsets are supported. Operation is not guaranteed when used with USB hubs or expansion cards.
MAC	OS： macOS® 10.14 ~ 12\| CPU: Intel® Core i3 or faster \| USB: USB 3.0/USB 2.0* * Operation is not guaranteed when used with USB hubs or expansion cards.
IPHONE/IPAD	OS： iOS 9 ~ 15 * Apple Lightning-to-USB Camera Adapter required.
SAMPLING FREQUENCY	44.1/48/96 kHz
FREQUENCY CHARACTERISTICS	44.1 kHz: −1.0 dB, 20 Hz – 20 kHz \| 96 kHz: −3.0 dB, 20 Hz – 40 kHz
EQUIVALENT INPUT NOISE	Actual measurements: −128dB EIN (IHF-A) at +60dB/150Ω input
DISPLAY	LCD with backlight (128×64 resolution)
POWER	AD-19 AC adapter (DC12V 2A)
POWER CONSUMPTION	24 W maximum
EXTERNAL DIMENSIONS	445 mm (W) × 388.4 mm (D) × 82.6 mm (H)
WEIGHT (MAIN UNIT ONLY)	3.71 kg
