Mackie ProFX30v3 30-channel Mixer with USB and Effects
- Analog Mixer with USB Interface
- Channels: 30 (22 x mono, 4 x stereo)
- Computer Connectivity: USB (2 x 4)
- A/D Resolution: 24-bit/192kHz
- Faders: 30 x 60mm Faders
- Inputs - Mic Preamps: 2 x XLR-1/4" combo (mic/line/Hi-Z), 23 x XLR (mic)
- Phantom Power: Yes
- Inputs - Line: 20 x 1/4", 6 x 1/4" (3 x stereo), 1 x 1/8" (stereo)
- Outputs - Main: 2 x XLR, 2 x 1/4" (L/R), 2 x 1/4" (control room)
- Outputs - Other: 4 x 1/4" (sub group out)
- Aux Sends: 1 x FX Send (post), 2 x Monitor Send (pre), 1 x Monitor Send (pre/post)
- Send/Return I/O: 1 x 1/4" (FX send), 3 x 1/4" (monitor send)
- Busses/Groups: 2 x Sub Group
- Inserts: 22 x 1/4" (channel)
- Headphones: 1 x 1/4"
- USB: 1 x Type B
- Other I/O: 1 x 1/4" (footswitch)
- EQ Bands: 3-band EQ with Variable Mid Frequency (mic channels), 100Hz Low-cut Filter
- Signal Processing: 16 x Channel Compressors
- Effects: GigFX Engine: Reverbs, Chorus, Delay, Flange, Auto-Wah
- Software: Pro Tools First, Waveform OEM DAW, Additional Plug-in packages available
- Power Source: Standard IEC AC cable
- Height: 4.4"
- Width: 17.1"
- Depth: 32.3"
- Weight: 26.5 lbs.
