Mixer Mackie ProFX16v3
Mackie ProFX16v3 16-channel Mixer with USB and Effects
Type: Analog Mixer with USB Interface
Channels: 16 (8 x mono, 4 x stereo)
Computer Connectivity: USB (2 x 4)
A/D Resolution: 24-bit/192kHz
Faders: 16 x 60mm Faders
Inputs - Mic Preamps: 2 x XLR-1/4" combo (mic/line/Hi-Z), 9 x XLR (mic)
Phantom Power: Yes
Inputs - Line: 6 x 1/4", 6 x 1/4" (3 x stereo), 1 x 1/8" (stereo)
Outputs - Main: 2 x XLR, 2 x 1/4" (L/R), 2 x 1/4" (control room)
Outputs - Other: 4 x 1/4" (subgroup out)
Aux Sends: 1 x FX Send (post), 2 x Monitor Send (pre), 1 x Monitor Send (pre/post)
Send/Return I/O: 1 x 1/4" (FX send), 3 x 1/4" (monitor send)
Busses/Groups: 2 x Subgroup
Inserts: 8 x 1/4" (channel)
Headphones: 1 x 1/4"
USB: 1 x Type B
Other I/O: 1 x 1/4" (footswitch)
EQ Bands: 3-band EQ with Variable Mid Frequency (mic channels), 100Hz Low-cut Filter
Signal Processing: 8 x Channel Compressors
Effects: GigFX Engine: Reverbs, Chorus, Delay, Flange, Auto-Wah
Software: Pro Tools First, Waveform OEM DAW, Additional Plug-in packages available
Power Source: Standard IEC AC cable
Height: 4.4"
Width: 17.7"
Depth: 17.1"
Weight: 15.2 lbs.
