Frequency Response (-10dB) 380 Hz - 6 kHz
Coverage Pattern 50 degrees horizontal by 70 degrees vertical
Included High-Pass Filter Passive 350 Hz High-pass filter built-in to protect against damage from frequencies below operational range
Directivity Factor (Q) 15.8 (2 kHz)
Directivity Index (DI) 12.0 (2 kHz)
System Power Rating 30W (120W peak), 100 hours
Sensitivity (1W, 2.83V @ 1m) 108 dB, ave. 1 kHz - 6 kHz; 112 dB at 1.4 kHz
Max. SPL 123 dB cont ave. (129 dB peak), 1 kHz - 6 kHz; 127 dB cont ave. (133 dB peak), 1.4 kHz, 30W input, 8 ohm setting
Nominal Impedance 30W/70V, NC/100V tap: 167 ohms; 15W/70V, 30W/100V tap: 333 ohms;
Transformer Taps 70V: 30W, 15W, 7.5W, 3.8W, 1.9W; 100V: 30W, 15W, 7.5W, 3.8W
Driver 38 mm (1.5") diameter with phenolic diaphragm
Horn Material ABS
