Frequency Response (-10dB) 400 Hz - 7.5 kHz
Coverage Pattern 70 degrees horizontal by 90 degrees vertical
Included High-Pass Filter Passive 350 Hz High-pass filter built-in to protect against damage from frequencies below operational range
Directivity Factor (Q) 10.9 (2 kHz)
Directivity Index (DI) 10.4 (2 kHz)
System Power Rating 15W (60W peak), 100 hours
Sensitivity (1W, 2.83V @ 1m) 105 dB, ave. 1 kHz - 6 kHz; 111 dB at 2 kHz
Max. SPL 117 dB cont ave. (123 dB peak), 1 kHz - 6 kHz; 123 dB cont ave. (129 dB peak), 2 kHz, 15W input, 8 ohm setting
Nominal Impedance 15W/70V, NC/100V tap: 333 ohms; 7.5W/70V, 15W/100V tap: 667 ohms; 3.8W/70V, 7.5W/100V tap: 1333 ohms; 1.9W/70V, 3.8W/100V tap: 2666 ohms; 0.9W/70V, 1.9W/100V tap: 5332 ohms; 8 ohms at 8 ohm direct setting
Transformer Taps 70V: 15W, 7.5W, 3.8W, 1.9W, 0.9W; 100V: 15W, 7.5W, 3.8W, 1.9W
Full-Range Driver 33 mm (1.3") diameter with phenolic diaphragm
Horn Material ABS
