• Speaker cable includes 2 cores, 4 cores, 6 cores, 8 cores, etc.
• Conductor made of 99.99% OFC.
• Insulation made of highly flexible PVC.
• Jacket made of highly elastic PVC.
Cable model |
GB103 |
GB103-1 |
GB104 |
Inner conductor |
Φ0.12BC*66 |
Φ0.20BC*42 |
Φ0.20BC*48 |
Inner conductor section |
0.75 mm² |
1.3 mm² |
1.5 mm² |
conductor Isolation |
PVC Φ2.0 |
PVC Φ2.4 |
PVC Φ2.8 |
Isolation colour |
Blue/yellow |
Blue/yellow |
Blue/yellow |
Number of conductors |
2 |
2 |
2 |
Outer jacket |
Flexible PVC |
Flexible PVC |
Flexible PVC |
Outer jacket colour |
Black & Dark Blue |
Black & Dark Blue |
Black & Dark Blue |
Outer dimensions |
Φ5.5 mm |
Φ6.0 mm |
Φ7.0 mm |
Temperature range |
min. -20℃ |
min. -20℃ |
min. -20℃ |
Temperature range |
max. 70℃ |
max. 70℃ |
max. 70℃ |
Packaging |
100 m roll |
100 m roll |
100 m roll |
Lead resistance - 1k meter |
≤27 Ω |
≤16 Ω |
≤13 Ω |
