Crosover DBX 223s Stereo 2-Way/Mono 3-Way Crossover

Crossover 2wway DBX 223s

Mã sp : Crossover 2wway DBX 223s

Số lượng :

Giá bán: 5.000.000 Đ (giá tham khảo)

(Giá chưa bao gồm thuế 10% VAT)

Hotline: 0908677003

Input Connectors	1/4" TRS
Input Type	Electronically balanced/unbalanced, RF filtered
Input Impedance	Balanced >50k ohm, unbalanced >25k ohm
Max Input	>+22dBu balanced or unbalanced
CMRR	>40dB, typically >55dB at 1kHz
Output Connectors	1/4" TRS
Output Type	Impedance-balanaced/unbalanced, RF filtered
Output Impedance	Balanced 200 ohm, unbalanced 100 ohm
Max Output	>+21dBu balanced/unbalanced into 2k ohms or greater
Bandwidth	20Hz to 20kHz, +/-0.5dB
Frequency Response	< 3 Hz to > 90 kHz, +0/-3 dB
Signal to Noise Ratio	Ref: +4 dBu, 22 kHz measurement bandwidth
Signal-to-Noise (Stereo Mode)	>94dB (Low Output), >91dB (High Output)
Signal-to-Noise (Mono Mode)	>94dB (Low Output), >93dB (Mid Output), >91dB (High Output)
Dynamic Range	> 106 dB, unweighted, any output
THD+Noise	< 0.004% at +4 dBu, 1 kHz; < 0.04% at +20 dBu, 1 kHz
Interchannel Crosstalk	< -80 dB, 20 Hz to 20 kHz
Crossover Frequencies (Stereo Mode)	Low/High: 45 to 960 Hz or 450 Hz to 9.6 kHz (x10 setting)
Crossover Frequencies (Mono Mode)	Low/Mid: 45 to 960 Hz or 450 Hz to 9.6 kHz (x10 setting); Mid/High: 45 to 960 Hz or 450 Hz to 9.6 kHz (x10 setting)
Crossover Filter Type	Linkwitz-Riley, 24 dB/octave, state-variable
Low cut Switch	Activates 40 Hz Butterworth, 12 dB/octave high-pass filter, one switch per channel.
Phase Invert Switch	Inverts the phase at the output, one switch per output.
x1 / x10 Switch	Multiplies the low-high(mono: low/mid and high/mid) crossover frequency range of the front-panel markings by a factor of 1 or 10, one switch per channel.
Mode Switch	Selects stereo/mono and 2/3-way operation
LF Sum Switch	Selects normal (stereo) or mono-summed low frequency operation and disables Ch 2’s low output phase invert LED to indicate that this output is not operational in the LF sum mode.
Indicators	Stereo Operation (Green); Mono Operation (Yellow); Low Cut (Red-per channel); x10 (Green-per channel); Phase Invert (Red-per output)
Operating Voltage	100 VAC 50/60 Hz; 120 VAC 60 Hz 230 VAC50 HZ
Operating Temperature	32°F to 113°F (0°C to 45°C)
Power Consumption	15W
Power Connector	IEC receptacle
Dimensions	1.75" H X 19" W X 6.9" D (4.4cm x 48.3cm x 17.5cm)
Unit Weight	3.7 lbs. (1.7 kg)
Shipping Weight	5.4 lbs. (2.5 kg)
